SANY STR30C-8 Tandem Drum Road Roller

SANY STR30C-8 Tandem Drum Road Roller

SPECIFICATIONS

SANY STR30C-8 Tandem Drum Road Roller

Description
Featuring exceptional compaction performance, our SANY road rollers greatly meet the demands of compaction for asphalt road and cement-stabilised base. The advanced hydraulic system offers higher efficiency and more productivity: Sufficient power to operate on slopes Three stage fuel filter system Engine cover opens wide to provide easy access for maintenance ENGINE MODEL: YANMAR T3 OPERATING WEIGHT: 3000KG
WEIGHT AND LOAD
Operating weight (kg)
3000
Weight at drum (kg)
1450
Weight at rear axle (kg)
1550
Front drum static liner load (N/cm)
118
Rear drum static liner load (N/cm)
126
COMPACTION
Vibration frequency (Hz)
55/67
Nominal amplitude (mm)
0.5
Centrifugal force (kN)
46/28
Drum diameter (mm)
700
Drum width (mm)
1200
Drum edge thickness (mm)
14
MANEUVRABILITY
Travel speed (km/h)
0~11
Working speed (km/h)
0~6
Theoretical gradeability (vibratory)
30%
Theoretical gradeability (non-vibratory)
40%
Ground clearance (mm)
240
Wheelbase (mm)
1700
Steering angle (°)
±30
Swing angle (°)
± 6
Min. turning outside diameter (mm)
7050
ENGINE
Brand
YANMAR
Model
3TNV88-BDTYC
Cooling system
Water cooling
Emission
GB 20891-2014 STAGE â…¢
Rate speed (rpm)
3000(gross)
Rated net power (kW)
28.1
CAPACITY
Battery (V×Ah)
12×40
Water tank (L)
160
Fuel tank (L)
40
Hydraulic oil tank (L)
28

RELIABLE AND EFFICIENT POWER

  • Sufficient power to operate on slopes.
  • Three stage fuel filter system.
  • Engine cover opens wide to provide easy access for maintenance.

ADVANCED HYDRAULIC SYSTEM

  • The closed loop hydraulic system has three filters for greater reliability.

DRUM VIBRATION TECHNOLOGY

  • The use of water wheel type lubrication on the vibratory bearing extends the bearing life up to 5,000 hours.
  • Drum evenness and smoothness meets stringent highway surface work requirements.
  • Road surface clearance height at the edge can be up to 825mm.

RELIABLE OIL-SPRAYING SYSTEM

  • 800L plastic lined water tanks provide water for up to 5.7 continuous hours of work.
  • Optimized spray amount prevents asphalt from sticking to drums and limits asphalt cooling.
  • A back-up spray pump for greater reliability.

EFFICIENT CONTROL SYSTEM

  • The operating controls can swing up to 90° right or left to allow the operator a clear view when working at the road edges.
  • The speed and direction control joystick are integrated for greater control.

OPERATOR COMFORT & SAFETY FEATURES

  • Cab mounted on three stage vibration damping mounts.
  • Cab climate control.
  • Specially designed parking brake system.
